MF 1035 DI Shakti

SPECIFICATIONS :-

Make :-    MF & Tafe
Model:-    MF 1035 DI

Drive:-     2WD

  Engine

     Simpson S324 T III A Engine
Type:-                      DI, 4 Stroke, Diesel
Horse power:-         35 HP

No. of cylinders :-    3

Cubic Capacity:-     2400cc
Pump:-                     Inline

                         Transmission

Sliding Mesh
No. of gears :-          8F+2R
Forward Speed :-    29.4 kmph

                          Hydraulics

live hydraulic pump

Pump type :- Gear Pump

                          Towing-Hitch

Lift capacity :-   1100 kg

Hitch :-               3 point , CAT II


                           Steering

Mechanical steering

                           Power take off

Two Speed PTO

PTO hp:-            32hp
No. of splines :-  6
PTO rpm:-         540 @ 1650 Erpm

                            Clutch

Single Dry type
Heavy duty

                       Cooling and cleaning

Forced water cooled
Oil bath type air cleaner

                          Electrical

battery :- 12v  75AH battery
plough lamp,registration lamp.

                          Brakes

Dry Disk Brakes (Dura brakes)
Mechanical Actuation
                         Dimensions(mm)

Total Length:-             3010
Total Width:-              1675
Total Height:-             2185
Wheel Base:-               1800
Ground Clearance:-   340
Turning Radius:-        2800
Total Weight(kg):-      1620
                       Capacities(ltr.)

Fuel Tank:-                 47

                          Tires

Front tires:-              6.00-16,   8Ply Rating

Rear tires :-              12.4-28,  12Ply Rating
